Dimensional Calibration
All of our dimensional calibration services meet industry regulations. Plus, BEVOGTE Metrology holds our technicians and services to our high personal standards. We’re committed to meeting the specifications set by our customers and exceeding your expectations.
BEVOGTE offers comprehensive physical dimensional calibration services. Gauges and equipment received at our facility are first sent to our cleaning room if applicable, then stabilized for 24 hours, and calibrated in our environmentally controlled lab. The professional, courteous BEVOGTE Metrology technicians will deliver our services with limited disruption to your workflow. We also share all information about necessary adjustments and repairs. our certified technicians have the experience to work in various manufacturing environments.
| Instrument | Calibration Range |
|---|---|
| Vernier Caliper | 0-1000 mm |
| Vernier Depth Gauge | 0-1000 mm |
| Vernier Height Gauge | 0-1000 mm |
| External Micrometer | U 1 b Hit |
| Micrometer Setting Standard | 0-1000 mm |
| Inside Micrometer | 5-2000mm |
| Depth Micrometer | 0-300 mm |
| Lever Dial | 0-100 mm |
| Plunger Dial | 0-100 mm |
| Bore Gauge | 1mm travel |
| Pistol Caliper | 0-50 mm |
| Bevel Protractor / Combination Set | 0-360 deg. |
| Dial Thickness Gauge | 0-5 mm |
| Feeler Gauge | 0-5 mm |
| Pin Gauge | 0-25mm |
| Thickness Foil | 0-5mm |
| Dial Snap Gauge | upto 400 mm |
| Description | Range | Master Used |
|---|---|---|
| Micrometer, Height Gauge, Vernier Caliper | 0 to 1000 mm 0 to 2000 mm | Grade ‘0’ Slip Gauge Set, Length Bar Set |
| Plunger / Lever / Bore Dial Gauge | 0 to 100 mm | Dial Calibration Tester |
| Coating Thickness Gauge | 0 to 10 mm | Elcometer Standard Foils |
| Measuring Scale / Tape, PI Tape | 0 to 100 m | Scale and Tape Calibrator |
| Test Sieve | Up to 200 mm | Profile Projector |
| Electronic Level / Spirit Level | Any Range | Robust Tilting Table with Electronic Level/td> |
| Bevel Protractor, Combination Set | 0 to 360° | Profile Projector |
| Radius Gauge, Pitch Gauge | Profile Projector | |
| Weld Fillet / Weld Gauge | Profile Projector | |
| Plain Plug / Width / Pin / Snap / Feeler Gauge | Up to 200 mm | Digital Comparator & Grade ‘0’ Slip Gauge set |
| Profile Projector, Video Measuring M/C, Microscope | Up to 300 mm 0 to 360° Up to 100 X |
Glass Scale Anuglar Graticule |
| Straight Edge | Up to 5 m | Electronic Level |
| Dial Thickness Gauge, Pistol Caliper | 0 to 100 mm | Grade ‘0’ Slip Gauge Set |
| LVDT Probe | 0 to 600 mm | Grade ‘0’ Slip Gauge Set |
| Ultrasonic Thickness Gauge | Up to 200 mm | Grade ‘0’ Slip Gauge Set |
| Surface Plate / Table | 3 x 5 Meter | Precision Spirit Level |
| Thread Plug Gauge | Up to 100 mm | FCDM |
| Dial Caliper Gauge (Internal / External) | Up to 150 mm | Using Slip Gauge accessories set |
| Hegmann Gauge, Wet / Dry Film Applicator | Any Range | Profile Projector & Digital Comparator |
